Bơm ly tâm đa tầng cánh

LIQUIDS

Fresh water, drinking water, boiler feed water, process water, sea and brackish water, hot water, condensate, lyes, etc

MATERIALS

Depending on the requirements of the liquids or the customers’ requests, available in cast iron, stainless steel, bronze

TECHNICAL DATA

• Capacity up to 220 m3/h (970 USGPM)

• Head up to 400 m (1312 ft)

• Speed up to 3.500 rpm

• Temperature up to 140 °C (284 °F)

• Casing Pressure up to 40 bar

• Shaft Sealing Gland packing or mechanical seals*

• Lubrication Antifriction bearings grease lubricated Slide bearings liquid lubricated

• Flange Discharge branch: from DN 32 to DN 80 Suction flange: DIN 2535, PN 40 Discharge flange: DIN 2535, PN 40
